8 Passages 24 Circuits 2A Ethernet Rotary Joint For Converting Machinery

Brand Name : Hiscience

Model Number : HK56-0801-P2402

Certification : ISO

Place of Origin : Shenzhen , China

MOQ : 1

Payment Terms : T/T

Price : Negotiate

Packaging Details : Carton

Delivery Time : 2-30 Days, Stock Available

Supply Ability : 1000 PCS/Week, Stock Available

Name : Rotary Unions

NO.of Circuits : 24 / 2A

Lead Wire Size : AWG26#Teflon Insulated

Voltage : 240VAC/DC

Lead Length : Stator:250mm Rotor :250mm

Housing Material : Engineering Plastics/ Metals(optional)

Contact Now

Rotary Unions 8 Passages with 24 Circuits 2A

Product Description:

Features:

  • High-Speed Operation: The Rotary Union is designed to support high-speed operation, making it suitable for applications that require rapid signal transmission or rotating machinery with high rotational speeds. Its robust construction and precise engineering enable stable signal transmission even at high speeds, ensuring accurate data transfer and control signal integrity.

  • Wide Temperature Range: The Rotary Union can operate within a wide temperature range, making it suitable for applications in extreme environments. It is designed to withstand both high and low temperatures, ensuring reliable performance and signal transmission in challenging conditions. This temperature versatility makes it ideal for industrial applications that involve temperature variations.

  • Customizable Options: The Rotary Union offers customizable options to meet specific application requirements. It can be tailored with various connector types, circuit configurations, and mounting options, allowing for seamless integration into different systems and equipment. This customization ensures compatibility and optimal performance in diverse industrial settings.

Typical Application:

  • Packaging Machinery for Pharmaceuticals: Electrical and Pneumatic Rotary Unions find application in packaging machinery for pharmaceutical products, enabling the transfer of power, control signals, and pneumatic signals to control the operation of filling, capping, and labeling equipment.

  • Converting Machinery: Rotary Unions are utilized in converting machinery, including printing presses, laminators, and slitter rewinders. They enable the transfer of power, control signals, and pneumatic signals for precise control of the converting processes.

  • Printing and Labeling Machines: Rotary Unions play a crucial role in printing and labeling machines by enabling the transfer of power, control signals, and compressed air. They facilitate the precise movement of print heads, label applicators, and other printing or labeling components.


Specifications:

Electrical& Electronics
NO.of Circuits 24 / 2A
Lead Wire Size AWG26#Teflon Insulated
Voltage 240VAC/DC
Insulation Resistance ≥300MΩ/300VDC
Dynamic Contact Resistance ≤35MΩ
Mechanical Parameter
Lead Length

Stator:250mm

Rotor :250mm

Working Speed 0~100RPM
Working Humidity ≤ 70%RH
Working Temperature -30℃~+80℃
Precious Metal Precious Metal
Housing Material Engineering Plastics/ Metals(optional)
Pneumatic Parameter
Passages 8
Connection Thread Size G1/8"
Pressure -100Kpa~1Mpa
Transmitting media Compressed Air
Rotating Speed 0~100RPM
Working Temperature -30℃~+80℃



Drawing for HK56-0801-P2402:

8 Passages 24 Circuits 2A Ethernet Rotary Joint For Converting Machinery

8 Passages 24 Circuits 2A Ethernet Rotary Joint For Converting Machinery

FAQ:

How can I ensure a leak-free operation?

Proper installation and maintenance are essential to ensure a leak-free operation. Regular inspection, cleaning, and lubrication of the Rotary Union components, as well as following manufacturer guidelines, can help maintain optimal sealing performance.

Can Rotary Unions handle both fluid and gas simultaneously?

Yes, certain Rotary Unions are designed to handle the simultaneous transfer of fluids and gases. These multi-channel Rotary Unions provide separate passages for different media, allowing for efficient and reliable transfer.

What maintenance is required for Rotary Unions?

Maintenance requirements may vary depending on the specific Rotary Union and application. Regular inspection, cleaning, lubrication, and replacement of worn components are typical maintenance practices to ensure optimal performance and longevity.
